Steel grating is specialized water treatment equipment that continuously and automatically intercepts and removes various debris from fluids. Widely used in urban sewage treatment, it also serves as front-end screening equipment in wastewater treatment processes for industries including textiles, food processing, papermaking, and leather manufacturing. This represents one of the most advanced solid-liquid screening solutions available.
Plain bar grating is one of the most versatile and widely used grating types due to its durability, cost-effectiveness, and reliability. Typically manufactured from carbon steel or stainless steel, it features a smooth, flat surface ideal for applications requiring strong load-bearing capacity and stability.
Serrated steel grating features bearing bars with serrated edges that provide superior non-slip performance and increased safety compared to plain grating. This design makes it ideal for environments where slip resistance is critical.
Also known as pressed or pressure lock grating, I-bar type is manufactured from low carbon steel, stainless steel, or aluminum. It's created by bonding two precisely slotted bars together under hydraulic pressure, forming a permanent, secure lock.
| Specification | Details |
|---|---|
| Bearing Bar | 25x3, 25x4, 25x4.5, 25x5, 30x3, 30x4, 30x4.5, 30x5, 32x5, 40x5, 50x5, 65x5, 75x6, 75x10-100x10mm etc I bar: 25x5x3, 30x5x3, 32x5x3, 40x5x3 etc US standard: 1"x3/16", 1 1/4"x3/16", 1 1/2"x3/16", 1"x1/4", 1 1/4"x1/4", 1 1/2"x1/4", 1"x1/8", 1 1/4"x1/8", 1 1/2"x1/8" etc |
| Bearing Bar Pitch | 12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3, 32.5, 34.3, 35, 38.1, 40, 41.25, 60, 80mm etc US standard: 19-w-4, 15-w-4, 11-w-4, 19-w-2, 15-w-2 etc. |
| Twisted Cross Bar Pitch | 38.1, 50, 60, 76, 80, 100, 101.6, 120mm, 2" & 4" etc |
| Material Grade | ASTM A36, A1011, A569, Q235, S275JR, SS304, SS400, Mild steel & Low carbon steel, etc |
| Surface Treatment | Black, self color, hot dip galvanized, painted, spray coating |
| Grating Style | Plain / Smooth, Serrated / teeth, I bar, serrated I bar |
| Standard | China: YB/T 4001.1-2007, USA: ANSI/NAAMM(MBG531-88), UK: BS4592-1987, Australia: AS1657-1985, Germany: DIN24537-1-2006, Japan: JIS |
