商品の詳細:
|
| ハイライト: | Anti-Slip Stainless Steel Bar Grating,304 316 Stainless Steel Grating,Multipurpose Metal Grating |
||
|---|---|---|---|
| Component | Material Options | Standard Specifications | Custom Options |
|---|---|---|---|
| Stanchions (Posts) | Carbon Steel (HDG), Stainless Steel (304/316) | Height: 42" (1067mm) standard; diameters: 1.5" - 2.5" OD | Custom heights, diameters, and laser-cut logos |
| Ball Joints | Forged Steel, Stainless Steel | Ball diameter: 2" - 3"; integrated weld-free clamp design | Color-matched powder coating, anti-slip texture |
| Handrails | Round, oval, or square tubing | 1.5" - 2" OD; length: 6' - 20' standard | Pre-drilled ends, bent sections, custom radii |
| Base Plates | Steel plate, cast iron | 4"×4" to 6"×6"; thickness: 1/4" - 1/2" | Slotted holes for adjustability, non-skip grating mounts |
| Mounting Hardware | Stainless steel or zinc-plated | T-bolts, grating clamps, anchor bolts | Security fasteners, quick-release pins |
| Infill Options | Vertical pickets, mid-rails, mesh panels | Pickets: 1/2" OD, spacing ≤ 4" | Cable systems, glass panels, perforated screens |
